Parts List
Trim sender
Diagram Reference: 1
Screw, with washer(6h2)
Diagram Reference: 2
Cam, trim sender
Diagram Reference: 3
Screw, with washer
Diagram Reference: 4
Clamp
Diagram Reference: 5
Steering bracket assembly
Diagram Reference: 6
Steering bracket assembly
Diagram Reference: 6
Plug (1hx)
Diagram Reference: 7
Washer, plate (6e5)
Diagram Reference: 8
O-ring(61u)
Diagram Reference: 9
Bush(6e5)
Diagram Reference: 10
Washer, plate(61a)
Diagram Reference: 11
Housing, lower mount rubber 1
Diagram Reference: 12
Circlip (6e5)
Diagram Reference: 13
Damper, lower mount rubber
Diagram Reference: 14
Mount damper, lower side
Diagram Reference: 15
Washer, plate (6e5)
Diagram Reference: 16
Washer, plate (6e5)
Diagram Reference: 17
Bolt, flange
Diagram Reference: 18
Nut, crown
Diagram Reference: 19
Washer (6e5)
Diagram Reference: 20
Cover, lower mount
Diagram Reference: 21
Bolt, with washer
Diagram Reference: 22
Mount damper, upper side
Diagram Reference: 23
Bolt, flange deep recess
Diagram Reference: 24
Bolt, flange
Diagram Reference: 25
Plate
Diagram Reference: 26
