Parts List
Bracket, clamp
Diagram Reference: 1
Pad, transom clamp
Diagram Reference: 2
Screw, transom
Diagram Reference: 3
Pin (663)
Diagram Reference: 4
Handle, transom clamp
Diagram Reference: 5
Anode
Diagram Reference: 6
Screw, countersunk
Diagram Reference: 7
Bracket, clamp
Diagram Reference: 8
Wire, lead 5
Diagram Reference: 13
Screw, pan head(62j)
Diagram Reference: 14
Bolt, clamp bracket 2
Diagram Reference: 15
Collar(697)
Diagram Reference: 16
Washer, plate
Diagram Reference: 17
Nut(624)
Diagram Reference: 18
Bracket, swivel
Diagram Reference: 19
Bracket, swivel
Diagram Reference: 19
Rivet (663)
Diagram Reference: 20
Nipple, grease(6a1)
Diagram Reference: 21
Cap, grease nipple
Diagram Reference: 22
Pin, spring (663)
Diagram Reference: 23
Bolt, clamp bracket
Diagram Reference: 24
Bushing (688)
Diagram Reference: 25
Washer, plate(64j)
Diagram Reference: 26
Nut, self-locking
Diagram Reference: 27
Cap, clamp bracket
Diagram Reference: 28
Lever, tilt stop 1
Diagram Reference: 29
Lever, tilt stop 2
Diagram Reference: 30
Bush (663)
Diagram Reference: 31
Washer, wave (688)
Diagram Reference: 32
Collar
Diagram Reference: 33
Pin cotter
Diagram Reference: 34
Cover
Diagram Reference: 35
Tilt lock ass'y
Diagram Reference: 36
Shaft, tilt lock
Diagram Reference: 37
Pin, cotter(6l5)
Diagram Reference: 38
Spring tenssion(663)
Diagram Reference: 39
Rod, tilt lock 1
Diagram Reference: 41
Rod, tilt lock 1
Diagram Reference: 41
Nut (661)
Diagram Reference: 42
Nut, conection
Diagram Reference: 43
Pin, clevis
Diagram Reference: 44
Pin, cotter (648)
Diagram Reference: 45
Tilt rod assembly
Diagram Reference: 46
Stopper plate, titl lock rod
Diagram Reference: 47
Pin, spring (663)
Diagram Reference: 48
Spring, conical(6f5)
Diagram Reference: 49
Steering bracket assembly
Diagram Reference: 50
Steering bracket assembly
Diagram Reference: 50
Washer, plate(6h1)
Diagram Reference: 51
Bush
Diagram Reference: 52
Oil seal (688)
Diagram Reference: 53
Washer plate(663)
Diagram Reference: 54
Housing, lower mount rubber
Diagram Reference: 55
Circlip (688)
Diagram Reference: 56
Mount damper, lower side
Diagram Reference: 57
Washer, plate (679)
Diagram Reference: 58
Washer plate (663)
Diagram Reference: 59
Washer, plate (679)
Diagram Reference: 60
Bolt(663)
Diagram Reference: 61
Damper, lower mount 1
Diagram Reference: 62
Nut crown(663)
Diagram Reference: 63
Housing, lower mount rubber
Diagram Reference: 64
Bolt, hexagon deep recess
Diagram Reference: 65
Ybs67-8 washer, spring
Diagram Reference: 66
Spring, compression(64j)
Diagram Reference: 67
Nut(663)
Diagram Reference: 68
Cover, lower mount
Diagram Reference: 69
Screw, pan head(6b0)
Diagram Reference: 70
Wire, lead 2
Diagram Reference: 71
Wire, lead 2
Diagram Reference: 71
Mount damper, upper side
Diagram Reference: 72
Bolt(663)
Diagram Reference: 73
Washer, plate(663)
Diagram Reference: 74
Washer, plate(670)
Diagram Reference: 75
Washer, plate (663)
Diagram Reference: 76
Nut, self-locking
Diagram Reference: 77
Damper, upper mount
Diagram Reference: 78
Cover, upper mount
Diagram Reference: 79
Bolt(70w)
Diagram Reference: 80
Bolt, stud
Diagram Reference: 82
Nut, self-locking
Diagram Reference: 83
Bolt
Diagram Reference: 84
Washer, plate
Diagram Reference: 85
Washe, plate(663)
Diagram Reference: 86
