Diagram: CL5 DISPLAY

Diagram

Parts List

6YM8371016 (WITHOUT Wi-Fi)
Cl5 display(with wi-fi)
Diagram Reference: 1
Get Part
6YM8371006 (WITH Wi-Fi)
-
Diagram Reference: 1
Get Part
6YM2248000
Seal assembly
Diagram Reference: 2
Get Part
6YM8395600
Cap 1
Diagram Reference: 3
Get Part
6YD8395700
Cap 2
Diagram Reference: 4
Get Part
6YM8351200
Ring, speed meter
Diagram Reference: 5
Get Part
6YM8727800
Cover, meter
Diagram Reference: 6
Get Part
6YM8355300
Conversion harness cl5-pigtail
Diagram Reference: 7
Get Part
6YD8356N00
Wire, lead
Diagram Reference: 8
Get Part
