Parts List
Conversion harness cl5-pigtail
Diagram Reference: 1
Wire, lead
Diagram Reference: 2
Multi-hub
Diagram Reference: 3
End of line resister
Diagram Reference: 4
Wire, lead
Diagram Reference: 5
Main bus wire 3.0m-10ft
Diagram Reference: 6
Main bus wire 9.1m (30ft)
Diagram Reference: 6
Main bus wire 7.6m (25ft)
Diagram Reference: 6
Main bus wire 6.1m (20ft)
Diagram Reference: 6
Main bus wire 4.6m (15ft)
Diagram Reference: 6
Main bus wire 0.3m-1ft
Diagram Reference: 6
Pigtail bus wire 0.6m-2ft
Diagram Reference: 7
Pigtail bus wire 3.6m-12ft
Diagram Reference: 7
9ft pigtail bus
Diagram Reference: 7
Pigtail bus wire 1.8m-6ft
Diagram Reference: 7
Pigtail bus wire 0.9m-3ft
Diagram Reference: 7
1ft pigtail bus
Diagram Reference: 7
White cap 1 (4pin)
Diagram Reference: 8
Red cap 1 (2pin)
Diagram Reference: 9
Single-hub
Diagram Reference: 10
Sensor assembly
Diagram Reference: 11
Interface Unit Set
Diagram Reference: 12
Interface Unit
Diagram Reference: 13
Agi harness
Diagram Reference: 14
