Diagram: CONTROL

Diagram

Parts List

68DG411100
Handle, gear shift
Diagram Reference: 1
Get Part
9868005520
Ybs53-520 screw,flat head
Diagram Reference: 2
Get Part
68DG411900
Shaft, Change
Diagram Reference: 3
Get Part
68DG412201
Bushing, shift rod lever
Diagram Reference: 4
Get Part
9321009350
O-ring
Diagram Reference: 5
Get Part
9050112802
Spring,compression
Diagram Reference: 6
Get Part
9350516024
Ball
Diagram Reference: 7
Get Part
68DG412100
Lever, Shift Rod
Diagram Reference: 8
Get Part
9011905M04
Bolt, with washer
Diagram Reference: 9
Get Part
67D4414301
Rod, Shift
Diagram Reference: 10
Get Part
9299005600
Washer, plain (646)
Diagram Reference: 11
Get Part
9149016010
Pin, cotter
Diagram Reference: 12
Get Part
68DG414500
Connector, shift rod 1
Diagram Reference: 13
Get Part
68DG414600
Connector, shift rod 2
Diagram Reference: 14
Get Part
9011906ME0
Bolt, with washer
Diagram Reference: 15
Get Part
