Parts List
Oil seal (6g8)
Diagram Reference: 1
Oil seal
Diagram Reference: 2
Plane bearing, crankshaft 1
Diagram Reference: 4
Plane bearing, crankshaft 1
Diagram Reference: 4
Plane bearing, crankshaft 1
Diagram Reference: 4
Connecting rod kit
Diagram Reference: 5
Bolt, connecting rod
Diagram Reference: 6
Piston (std)
Diagram Reference: 7
Piston (0.25mm o/s)
Diagram Reference: 7
Piston (0.50mm o/s)
Diagram Reference: 7
Piston ring set (std)
Diagram Reference: 8
Ring piston
Diagram Reference: 8
Piston ring set (0.50mm o/s)
Diagram Reference: 8
Pin, piston
Diagram Reference: 9
Circlip 131116340000
Diagram Reference: 10
