Parts List
Housing, oil seal
Diagram Reference: 1
O-ring (688)
Diagram Reference: 2
Oil seal
Diagram Reference: 3
Oil seal (6g8)
Diagram Reference: 4
Bolt, hexagon deep recess
Diagram Reference: 5
Washer, plain (646)
Diagram Reference: 6
Crankshaft assembly
Diagram Reference: 7
Crank 1
Diagram Reference: 8
Crank 2
Diagram Reference: 9
Crank 3
Diagram Reference: 10
Crank 4
Diagram Reference: 11
Bearing
Diagram Reference: 12
Bearing
Diagram Reference: 13
Seal, labyrinth 1
Diagram Reference: 14
Pin crank
Diagram Reference: 15
Rod, connecting
Diagram Reference: 16
Bearing, cylindrical(6k4)
Diagram Reference: 17
Washer, crank pin (1h9)
Diagram Reference: 18
Pin, spring
Diagram Reference: 19
Circlip (168)
Diagram Reference: 20
Piston (std)
Diagram Reference: 21
Piston (1st o.s)
Diagram Reference: 21
Piston (2nd o.s)
Diagram Reference: 21
Piston ring set (std)
Diagram Reference: 22
Piston ring set (1st o/s)
Diagram Reference: 22
Piston ring set (2nd o/s)
Diagram Reference: 22
Pin, piston
Diagram Reference: 23
Pin, dowel
Diagram Reference: 24
Washer, plate
Diagram Reference: 25
Circlip 131116340000
Diagram Reference: 26
Oil seal (682)
Diagram Reference: 27
Spacer
Diagram Reference: 28
Washer, plate(63v)
Diagram Reference: 29
