Diagram: CYLINDER. CRANKCASE 2

Diagram

Parts List

67F−11133−10
Guide, intake valve
Diagram Reference: 3
Get Part
90344−51019
Plug, taper screw
Diagram Reference: 4
Get Part
90119−07235
Bolt, with washer
Diagram Reference: 5
Get Part
91809−08006
Pin, dowel
Diagram Reference: 6
Get Part
90119−07234
Bolt, with washer
Diagram Reference: 7
Get Part
68V−11325−00
Anode
Diagram Reference: 8
Get Part
97075−06020
Bolt(7u8)
Diagram Reference: 10
Get Part
92995−06600
Washer, plain (646)
Diagram Reference: 11
Get Part
67F−11328−00
Grommet, anode
Diagram Reference: 12
Get Part
97075−08025
Bolt, hexagon deep recess
Diagram Reference: 13
Get Part
92995−08600
Washer, plain (663)
Diagram Reference: 14
Get Part
97095−08014
Bolt, hexagon deep recess
Diagram Reference: 15
Get Part
90430−08143
Gasket (256-11198-00)
Diagram Reference: 16
Get Part
67F−11181−01
Gasket, cylinder head 1
Diagram Reference: 17
Get Part
90387−10M08
Pin, dowel
Diagram Reference: 18
Get Part
90105−10M89
Bolt, washer based
Diagram Reference: 19
Get Part
90119−08M91
Bolt, with washer
Diagram Reference: 20
Get Part
67F−11168−00
Cover, breather
Diagram Reference: 22
Get Part
98507−04008
Screw, pan head(jg1)
Diagram Reference: 23
Get Part
92907−04600
Washer(jf2)
Diagram Reference: 24
Get Part
90480−12072
Grommet(53y)
Diagram Reference: 25
Get Part
67F−11356−00
Seal, cylinder 2
Diagram Reference: 26
Get Part
97095−06030
Bolt(jf7)
Diagram Reference: 27
Get Part
67F−11192−00
Cover, cylinder head 2
Diagram Reference: 29
Get Part
90159−06M29
Screw, with washer
Diagram Reference: 30
Get Part
68V−12411−00
Thermostat
Diagram Reference: 31
Get Part
68V−12413−00−1S
Cover, thermostat
Diagram Reference: 32
Get Part
97095−06025
Bolt
Diagram Reference: 33
Get Part
6G8−15363−00
Plug, oil
Diagram Reference: 35
Get Part
93210−24M79
O-ring
Diagram Reference: 36
Get Part
94702−00391
Plug, spark (lfr5a-11)
Diagram Reference: 37
Get Part
