Rigging - Meter (2024)
DIGITAL NETWORK GAUGE 6
Diagram: DIGITAL NETWORK GAUGE 6
Parts List
Reference
Description
Price
1
63P8A4L207
Sensor, Module 2
Loading…
↗
2
6AW8366B10
Sensor, water pressure
Loading…
↗
3
63P8366C00
Adaptor, input
Loading…
↗
4
9043014115
Gasket (663)
Loading…
↗
5
60V8366D00
Adaptor, input
Loading…
↗
6
9010906M81
Bolt
Loading…
↗
7
9046511M10
Clamp
Loading…
↗
8
9044507017
Hose (l550)
Loading…
↗
9
9044707013
Hose, cover (l: 700mm)
Loading…
↗
10
60V4262901
Seal
Loading…
↗
11
97E9506516
Bolt, hexagon w/w deep recess
Loading…
↗
