Diagram: EKS ASSY (TWIN)

Diagram

Parts List

6ES8251012 (*1 ASK TO MARINE DIV)
Eks assembly, Without Ek Fob
Diagram Reference: 1
Get Part
6ES8338300
Buzzer
Diagram Reference: 2
Get Part
6ES8254300
Gasket
Diagram Reference: 3
Get Part
6ES4815600
Nut 1
Diagram Reference: 4
Get Part
6ES8251100 (*1 ASK TO MARINE DIV)
Key, main switch
Diagram Reference: 5
Get Part
6ES8256800
Eks cover (twin)
Diagram Reference: 10
Get Part
6ES8258A40
Eks harness (twin)
Diagram Reference: 11
Get Part
