Parts List
Bracket
Diagram Reference: 1
Bolt (6e0)
Diagram Reference: 2
Coller (6e9)
Diagram Reference: 3
Grommet(6h2)
Diagram Reference: 4
C.d.i. unit assembly
Diagram Reference: 5
Cover, lead wire
Diagram Reference: 6
Bolt, hexagon w/w deep recess
Diagram Reference: 7
Bolt, with washer(6g4)
Diagram Reference: 8
Rectifier & regulator assembly
Diagram Reference: 9
Bolt, with washer(6r6)
Diagram Reference: 10
Clamp(6j8)
Diagram Reference: 11
Cover, terminal
Diagram Reference: 12
Screw, with washer (6f5)
Diagram Reference: 13
Holder, fuse
Diagram Reference: 14
Clamp
Diagram Reference: 15
Clamp (6e5)
Diagram Reference: 16
Ignition coil assembly
Diagram Reference: 17
Bolt, with washer(61b)
Diagram Reference: 18
Plug cap assembly
Diagram Reference: 19
Relay assembly
Diagram Reference: 20
Bolt, hexagon deep recess
Diagram Reference: 21
Case 2
Diagram Reference: 22
Clamp (3y2)
Diagram Reference: 23
Battery cable
Diagram Reference: 24
Wire, lead
Diagram Reference: 25
Wire harness assembly
Diagram Reference: 26
Fuse
Diagram Reference: 27
Clamp
Diagram Reference: 30
Thermo switch assembly
Diagram Reference: 31
Relay assembly
Diagram Reference: 32
Bolt, hexagon w/w deep recess
Diagram Reference: 33
Case
Diagram Reference: 34
Wire, lead
Diagram Reference: 35
Wire, lead
Diagram Reference: 36
Cover, lead wire
Diagram Reference: 37
Trim & tilt switch assembly
Diagram Reference: 38
Gasket
Diagram Reference: 39
Bracket
Diagram Reference: 40
Bolt, hexagon deep recess
Diagram Reference: 41
Clamp(6h1)
Diagram Reference: 42
Mark, caution
Diagram Reference: 43
