Parts List
Plate
Diagram Reference: 1
Bolt(gj3)
Diagram Reference: 2
Washer, plain (646)
Diagram Reference: 3
Clamp(4tr)
Diagram Reference: 4
Ignition coil assembly
Diagram Reference: 5
High tension cord assembly 1
Diagram Reference: 6
Clamp(62y)
Diagram Reference: 7
Clamp (6g5)
Diagram Reference: 8
Clamp
Diagram Reference: 9
Bolt
Diagram Reference: 10
Bracket, ignition coil
Diagram Reference: 12
Bracket, ignition coil
Diagram Reference: 13
Clamp
Diagram Reference: 14
Rectifier & regulator assembly
Diagram Reference: 15
Engine control unit assembly
Diagram Reference: 18
Bolt, hexagon deep recess
Diagram Reference: 19
Plate
Diagram Reference: 21
Plate, lock
Diagram Reference: 22
Lead wire assembly
Diagram Reference: 23
Plate
Diagram Reference: 24
Oil pressure switch assembly
Diagram Reference: 27
Cover
Diagram Reference: 28
Grommet(3aa)
Diagram Reference: 29
Band, switch cord
Diagram Reference: 30
Cover, meter
Diagram Reference: 31
Screw, tapping
Diagram Reference: 32
