Parts List
Hose, with spring
Diagram Reference: 1
Clamp
Diagram Reference: 2
Wire, lead
Diagram Reference: 3
Bolt(gh1)
Diagram Reference: 4
Washer, plain (646)
Diagram Reference: 5
Battery cable
Diagram Reference: 6
Bolt, hexagon deep recess
Diagram Reference: 7
Washer, plain (663)
Diagram Reference: 8
Nut(6l2)
Diagram Reference: 9
Ybs67-8 washer, spring
Diagram Reference: 10
Plate
Diagram Reference: 11
Plate
Diagram Reference: 12
Bolt, flange(jk3)
Diagram Reference: 13
Relay assembly
Diagram Reference: 14
Bolt, hexagon deep recess
Diagram Reference: 15
Wire, lead
Diagram Reference: 17
Wire Harness assembly
Diagram Reference: 18
Clamp(6e7)
Diagram Reference: 19
Tube
Diagram Reference: 20
Clamp, harness
Diagram Reference: 21
Wire Harness assembly 2
Diagram Reference: 22
Thermosensor assembly
Diagram Reference: 24
Washer, plate
Diagram Reference: 25
Trim & tilt switch assembly
Diagram Reference: 26
Gasket
Diagram Reference: 27
Bracket
Diagram Reference: 28
Cover, bottom
Diagram Reference: 29
Bracket
Diagram Reference: 30
Bracket
Diagram Reference: 31
Clamp(4kj)
Diagram Reference: 32
Bolt
Diagram Reference: 33
Bolt(gj3)
Diagram Reference: 34
Grommet
Diagram Reference: 35
Plate
Diagram Reference: 38
Clamp
Diagram Reference: 40
Hose(6m6)
Diagram Reference: 41
Clamp
Diagram Reference: 42
Bolt, hexagon w/w deep recess
Diagram Reference: 43
