Diagram: ELECTRICAL DBW REMO-CON 1
Parts List
Wire harness assembly 2
Diagram Reference: 1
Cap 2 (2p)
Diagram Reference: 2
Cap 1 (6p)
Diagram Reference: 3
Cap 1 (4p)
Diagram Reference: 4
Cap 1 (3p)
Diagram Reference: 5
Cap 1 (12p)
Diagram Reference: 6
Cap 2 (6p)
Diagram Reference: 7
Cap 2 (6p)
Diagram Reference: 8
White cap 1 (4pin)
Diagram Reference: 9
Cap 2
Diagram Reference: 10
Cover, lead wire
Diagram Reference: 11
Wire harness assembly 2
Diagram Reference: 12
Cap 2 (6p)
Diagram Reference: 18
Band
Diagram Reference: 23
Panel switch assembly
Diagram Reference: 24
Panel, switch
Diagram Reference: 25
Switch assembly
Diagram Reference: 26
Diode assembly
Diagram Reference: 27
