Parts List
Damper
Diagram Reference: 1
Pipe, joint 2
Diagram Reference: 2
Pipe, fuel 1
Diagram Reference: 3
Band 1
Diagram Reference: 4
Clamp
Diagram Reference: 5
Filter assembly
Diagram Reference: 6
Cup, filter (with tag)
Diagram Reference: 7
Clip
Diagram Reference: 8
Float, water level
Diagram Reference: 9
Gasket
Diagram Reference: 10
Element, filter (with tag)
Diagram Reference: 11
Bolt, with washer
Diagram Reference: 12
Collar (6h3)
Diagram Reference: 13
Grommet(6k7)
Diagram Reference: 14
Cover
Diagram Reference: 15
Bolt(gh1)
Diagram Reference: 16
Washer, plain (646)
Diagram Reference: 17
Clamp(4gy)
Diagram Reference: 18
Clamp(4ap)
Diagram Reference: 19
Fuel pipe comp. 2
Diagram Reference: 20
Tool kit
Diagram Reference: 21
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 22
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
O/m f350a/fl350a/f/fl300a'09
Diagram Reference: 23
