Diagram: GENERATOR
Parts List
Rotor assembly
Diagram Reference: 1
Coil, pulser
Diagram Reference: 2
Coil, charge
Diagram Reference: 3
Retainer, magneto base
Diagram Reference: 4
Collar (1m1)
Diagram Reference: 5
Bolt, washer based(63v)
Diagram Reference: 6
Bolt, flange(2uj)
Diagram Reference: 7
Key, woodruff
Diagram Reference: 8
Nut, hexagon 6481155500
Diagram Reference: 9
Washer, plate (4n0)
Diagram Reference: 10
