Diagram: INTAKE

Diagram

Parts List

61N−13610−00
Reed valve assembly
Diagram Reference: 1
Get Part
689−W0004−00
Reed set
Diagram Reference: 2
Get Part
648−13621−A1
Gasket, valve seat
Diagram Reference: 3
Get Part
61N−13641−01−1S
Manifold, intake 1
Diagram Reference: 4
Get Part
648−13645−A0
Gasket, manifold 1
Diagram Reference: 5
Get Part
97013−06035
Bolt(3rv)
Diagram Reference: 6
Get Part
92903−06600
Washer, plain (646)
Diagram Reference: 7
Get Part
61N−14198−00
Gasket
Diagram Reference: 8
Get Part
61N−14440−00
Silencer assembly, intake
Diagram Reference: 9
Get Part
93210−40659
O-ring(36y)
Diagram Reference: 10
Get Part
90119−06M94
Bolt, with washer
Diagram Reference: 11
Get Part
90387−06M26
Collar(61n)
Diagram Reference: 12
Get Part
682−41271−00
Knob, choke
Diagram Reference: 13
Get Part
689−41273−00
Grommet
Diagram Reference: 14
Get Part
6J8−41274−00
Grommet 2
Diagram Reference: 15
Get Part
689−41252−01
Lever, choke 1
Diagram Reference: 16
Get Part
61N−41256−00
Rod, choke 1
Diagram Reference: 17
Get Part
661−41262−02
Joint, choke lever
Diagram Reference: 18
Get Part
91690−40048
Pin, spring (689)
Diagram Reference: 19
Get Part
90465−06M88
Clamp
Diagram Reference: 20
Get Part
6A1−83625−41
Mark 5
Diagram Reference: 21
Get Part
6A1−83625−51
Mark 5
Diagram Reference: 22
Get Part
