Diagram: INTAKE

Diagram

Parts List

63V1361010
Reed valve assembly
Diagram Reference: 1
Get Part
63W1361000
Reed valve assembly
Diagram Reference: 1
Get Part
682W000400
Reed set
Diagram Reference: 2
Get Part
9709506020
Bolt(7u8)
Diagram Reference: 3
Get Part
9299506600
Washer, plain (646)
Diagram Reference: 4
Get Part
6B41444000
Silencer assembly, intake
Diagram Reference: 5
Get Part
9709506095
Bolt, hexagon deep recess
Diagram Reference: 6
Get Part
9015905007
Screw, with washer
Diagram Reference: 8
Get Part
9321035M86
O-ring(6l2)
Diagram Reference: 9
Get Part
6B44127100
Knob, choke
Diagram Reference: 10
Get Part
6B44127300
Grommet
Diagram Reference: 11
Get Part
6B44127400
Grommet 2
Diagram Reference: 12
Get Part
6B44126200
Joint, choke lever
Diagram Reference: 13
Get Part
6B44125200
Lever, choke 1
Diagram Reference: 14
Get Part
9169020010
Pin, spring
Diagram Reference: 15
Get Part
