Parts List
Silencer assembly, intake
Diagram Reference: 1
Grommet
Diagram Reference: 2
O-ring
Diagram Reference: 3
Pipe 4
Diagram Reference: 4
Hose, oil 1
Diagram Reference: 5
Clip(6k8)
Diagram Reference: 6
Gasket, manifold 3
Diagram Reference: 7
Gasket, manifold 2
Diagram Reference: 8
Bolt, hexagon socket head
Diagram Reference: 9
Washer, plate
Diagram Reference: 10
Manifold, intake 1
Diagram Reference: 11
Gasket, manifold 1
Diagram Reference: 12
Bolt, hexagon w/w deep recess
Diagram Reference: 13
Starter cable assembly
Diagram Reference: 14
Nut
Diagram Reference: 15
Stay
Diagram Reference: 16
Bolt (682)
Diagram Reference: 17
Washer, plain (646)
Diagram Reference: 18
