Diagram: INTAKE 2
Parts List
Collar
Diagram Reference: 1
Grommet(3aa)
Diagram Reference: 2
Bolt, flange
Diagram Reference: 3
Cover, manifold
Diagram Reference: 4
Bolt, flange(jk3)
Diagram Reference: 5
Delivery pipe assembly 1
Diagram Reference: 6
Pipe, delivery 1
Diagram Reference: 7
Injector
Diagram Reference: 8
Packing kit
Diagram Reference: 9
Clip
Diagram Reference: 10
Bolt (689)
Diagram Reference: 11
Bolt, with washer
Diagram Reference: 12
Bracket, fuel pump 1
Diagram Reference: 13
Fuel pump assembly
Diagram Reference: 15
Bush, fuel pump
Diagram Reference: 16
Bracket, fuel pump
Diagram Reference: 17
Bracket, fuel pump 2
Diagram Reference: 18
Bolt, flange deep recess
Diagram Reference: 19
Bolt, with washer
Diagram Reference: 20
Spacer
Diagram Reference: 21
Collar (6h3)
Diagram Reference: 22
Cap, blind
Diagram Reference: 23
Clamp
Diagram Reference: 24
Clamp
Diagram Reference: 25
Clamp(3ld)
Diagram Reference: 26
Canister assembly
Diagram Reference: 27
Holder
Diagram Reference: 28
Bolt, flange deep recess
Diagram Reference: 29
Bracket, canister
Diagram Reference: 30
Solenoid valve assembly
Diagram Reference: 31
Nut(661)
Diagram Reference: 32
Grommet
Diagram Reference: 33
