Yamaha Outboard Parts - LAYOUT CHART 5 (6X7) - Rigging - Remote Control (2018)

6X74820621 (NOT FOR SALE)

6x7 dbw flush mount sgl stn

Diagram Reference: 1

6X74820631 (NOT FOR SALE)

6x7 dbw flush mnt sgl/main st

Diagram Reference: 1

6X74820641 (NOT FOR SALE)

6x7 dbw flush mount 2nd stn

Diagram Reference: 1

64D8257022 (& 2 STATION MAIN)

64d power switch main st

Diagram Reference: 2

6X68257080 (STATION SUB)

Panel switch assembly - 2nd stn

Diagram Reference: 3

6X682570B0 (STATION MAIN & SUB)

Switch - station dual selector

Diagram Reference: 4

Diagram: LAYOUT CHART 5 (6X7)
