Yamaha Outboard Parts - LAYOUT CHART 6 (TRIPLE) - Digital Network Control (2010)

6X64820840 (NOT FOR SALE)

6x6 rc trple top mount sgl stn

Diagram Reference: 1

6X64820850 (NOT FOR SALE)

Remote Control assembly (Triple)

Diagram Reference: 1

6X68257050 (& 2 STATION MAIN)

Panel Switch assembly

Diagram Reference: 2

6X68257070 (& 2 STATION MAIN)

Panel Switch assembly

Diagram Reference: 3

6X682570F0 (STATION SUB)

Panel switch assembly

Diagram Reference: 4

6X68257090 (STATION SUB)

Lanyard switch -2nd station

Diagram Reference: 5

6X682570B0 (STATION MAIN & SUB)

Switch - station dual selector

Diagram Reference: 6

Diagram: LAYOUT CHART 6 (TRIPLE)
