Parts List
Lower unit assembly
Diagram Reference: 1
Casing, lower
Diagram Reference: 2
Bearing, cylindrical(6j8)
Diagram Reference: 3
Sleeve, drive shaft
Diagram Reference: 4
Shim (t:0.12mm)
Diagram Reference: 5
Shim (t:0.15mm)
Diagram Reference: 5
Shim (t:0.18mm)
Diagram Reference: 5
Shim (t:0,30mm)
Diagram Reference: 5
Shim (t:0.40mm)
Diagram Reference: 5
Shim (t:0.50mm)
Diagram Reference: 5
Shim (t:0.10mm)
Diagram Reference: 5
Brg, tapered roller (409)
Diagram Reference: 6
Nipple, hose
Diagram Reference: 7
Hose (l200)
Diagram Reference: 8
End, nipple
Diagram Reference: 9
Clamp
Diagram Reference: 10
Plug, straight screw
Diagram Reference: 11
Gasket
Diagram Reference: 12
Bracket
Diagram Reference: 13
Screw, tapping(6u1)
Diagram Reference: 14
Shift cam assembly
Diagram Reference: 15
Boot, shift rod
Diagram Reference: 16
Nut
Diagram Reference: 17
Housing, water pump
Diagram Reference: 18
Insert, cartridge
Diagram Reference: 19
Impeller
Diagram Reference: 20
Gasket,water pump 1
Diagram Reference: 21
Damper, water seal 2
Diagram Reference: 22
Key, woodruff(662)
Diagram Reference: 23
Housing, water pump
Diagram Reference: 24
Oil seal (663)
Diagram Reference: 25
O-ring (132)
Diagram Reference: 26
Gasket,water pump 2
Diagram Reference: 27
Outer plate, cartridge
Diagram Reference: 28
Gasket,cartridge outer plate
Diagram Reference: 29
Pin,dowel (626)
Diagram Reference: 30
Bolt, with washer(6h0)
Diagram Reference: 31
Bolt, with washer(6j8)
Diagram Reference: 32
Drive shaft comp.
Diagram Reference: 33
Pinion
Diagram Reference: 34
Nut(6j8)
Diagram Reference: 35
Gear
Diagram Reference: 36
Bearing(6j8)
Diagram Reference: 37
Shim, thrust (0.4t)
Diagram Reference: 38
Shim, thrust (0.5t)
Diagram Reference: 38
Shim, thrust (0.3t)
Diagram Reference: 38
Shim (t:0.18mm)
Diagram Reference: 38
Shim, thrust (0.15t)
Diagram Reference: 38
Shim (t:0.12mm)
Diagram Reference: 38
Shim (t:0.10mm)
Diagram Reference: 38
Shaft, propeller
Diagram Reference: 39
Spring compression648456360000
Diagram Reference: 40
Clutch, dog
Diagram Reference: 41
Pin straight 648456320000
Diagram Reference: 42
Ring, cross pin
Diagram Reference: 43
Plunger, shift
Diagram Reference: 44
Washer, plate(663)
Diagram Reference: 45
Gear
Diagram Reference: 46
Housing, bearing
Diagram Reference: 47
Bearing(2hr)
Diagram Reference: 48
Shim (t:0.40mm)
Diagram Reference: 49
Shim (t:0.50mm)
Diagram Reference: 49
Shim (t:0.30mm)
Diagram Reference: 49
Shim (t:0.18mm)
Diagram Reference: 49
Shim (t:0.15mm)
Diagram Reference: 49
Shim (t:0.12mm)
Diagram Reference: 49
Shim (t:0.10mm)
Diagram Reference: 49
Washer, thrust 2
Diagram Reference: 50
O-ring(6j8)
Diagram Reference: 51
Brg,cyl-cal roller 21g nt
Diagram Reference: 52
Oil seal
Diagram Reference: 53
Washer, claw(6a9)
Diagram Reference: 54
Nut
Diagram Reference: 55
Key, strait(663)
Diagram Reference: 56
