Parts List
Damper, water seal 1
Diagram Reference: 5
Damper, water seal 2
Diagram Reference: 2
Tube, water 1
Diagram Reference: 3
Tube, water 2
Diagram Reference: 4
Cover, water pump housing
Diagram Reference: 6
Tube, water 3
Diagram Reference: 7
Pin, dowel b (6e5)
Diagram Reference: 8
Bolt, stud
Diagram Reference: 9
Bolt, with washer
Diagram Reference: 9
Washer, plate
Diagram Reference: 10
Nut
Diagram Reference: 11
Bolt, with washer
Diagram Reference: 12
Bolt, hexagon w/w deep recess
Diagram Reference: 13
Bolt, with washer
Diagram Reference: 13
Guide, seal damper
Diagram Reference: 14
Damper, seal
Diagram Reference: 15
Cover, water inlet 1
Diagram Reference: 16
Cover, water inlet 2
Diagram Reference: 17
Screw, countersunk
Diagram Reference: 18
Nut nylon (sus)(ex4)
Diagram Reference: 19
Cover, water inlet 3
Diagram Reference: 20
Cover, water inlet 4
Diagram Reference: 22
Bolt, hexagon socket head
Diagram Reference: 23
Anode
Diagram Reference: 24
Washer
Diagram Reference: 25
Bolt, flange
Diagram Reference: 26
Cap
Diagram Reference: 27
Bolt, hexagon socket head
Diagram Reference: 28
Damper, water seal 3
Diagram Reference: 29
Tube, water 2
Diagram Reference: 30
Grommet, water tube 1
Diagram Reference: 31
Grommet, water tube 2
Diagram Reference: 32
Spacer 1
Diagram Reference: 33
Spacer 2
Diagram Reference: 34
Washer, plate(6u1)
Diagram Reference: 35
Nut, castle (6e5)
Diagram Reference: 36
Pin, cotter (663)
Diagram Reference: 37
Sws xl sds (3x16-1/4x15"-xl)
Diagram Reference: 38
Sws xl sds (3x16-1/4x17"-xl)
Diagram Reference: 38
Sws xl sds (3x15-1/2x19"-xl)
Diagram Reference: 38
Sws xl sds (3x15-1/4x21"-xl)
Diagram Reference: 38
Sws xl sds (3x15-1/4x23"-xl)
Diagram Reference: 38
Propeller damper rubber assembly
Diagram Reference: 39
