Diagram: OPTIONAL PARTS
Parts List
Heat exchanger assembly
Diagram Reference: 1
Joint 1
Diagram Reference: 2
Clip, pipe 1 (6e9)
Diagram Reference: 3
Pipe 1
Diagram Reference: 4
Screw, pan head (7h3)
Diagram Reference: 5
Stay
Diagram Reference: 6
Hose (l110)
Diagram Reference: 8
Hose (l40)
Diagram Reference: 9
Pipe 1
Diagram Reference: 10
Exchanger, heat
Diagram Reference: 11
Exchanger, heat
Diagram Reference: 12
Pipe, joint 3
Diagram Reference: 13
Pipe 1
Diagram Reference: 14
Pipe, joint 4
Diagram Reference: 15
Plate
Diagram Reference: 16
Plate
Diagram Reference: 17
