Parts List
Main bus wire 0.3m-1ft
Diagram Reference: 1
Wire, lead
Diagram Reference: 2
Interface Unit
Diagram Reference: 3
Analog gauge interface
Diagram Reference: 4
1ft pigtail bus
Diagram Reference: 5
Pigtail bus wire 0.9m-3ft
Diagram Reference: 5
Pigtail bus wire 1.8m-6ft
Diagram Reference: 5
9ft pigtail bus
Diagram Reference: 5
Pigtail bus wire 3.6m-12ft
Diagram Reference: 5
Sensor assembly
Diagram Reference: 6
Wire Harness assembly
Diagram Reference: 7
36Ft Rc - Pcu Harness
Diagram Reference: 8
10Ft Rc - Pcu Harness
Diagram Reference: 8
23Ft Rc - Pcu Harness
Diagram Reference: 8
5Ft Rc - Pcu Harness
Diagram Reference: 8
Ext Cable, Steering Sensor 6Ft
Diagram Reference: 9
Ext Cable, Steering Sensor 12F
Diagram Reference: 9
Ext Cable, Steering Sensor 18F
Diagram Reference: 9
