Diagram: THROTTLE BODY ASSY 3
Parts List
Delivery Pipe assembly 1
Diagram Reference: 1
Pipe, delivery 1
Diagram Reference: 2
Injector assembly
Diagram Reference: 3
Packing Kit
Diagram Reference: 4
Clip
Diagram Reference: 5
Delivery Pipe assembly 2
Diagram Reference: 6
Pipe, delivery 2
Diagram Reference: 7
Bolt, with washer
Diagram Reference: 11
