Diagram: UPPER CASING

Diagram

Parts List

68D−G5111−01−4D

Casing, Upper

Diagram Reference: 1

68D−G5113−A0

Gasket, upper casing

Diagram Reference: 2

90387−06806 (L)

Collar(6e0)

Diagram Reference: 10

97095−06035

Bolt(j52)

Diagram Reference: 4

92995−06600

Washer, plain (646)

Diagram Reference: 5

93700−06M03

Nipple, grease(6a1)

Diagram Reference: 6

647−45151−01

Cover, upper casing

Diagram Reference: 7

90480−10M13

Grommet (6e0)

Diagram Reference: 8

90119−06M77 (L)

Bolt, with washer

Diagram Reference: 11

6E0−45318−01 (L)

Bushing, drive shaft 3

Diagram Reference: 12

93420−22M03 (L)

Cir clip (6e0)

Diagram Reference: 13
