Diagram: VAPOR SEPARATOR 2
Parts List
Body, throttle 1
Diagram Reference: 1
Plate
Diagram Reference: 2
Screw
Diagram Reference: 3
Spring, air adjusting
Diagram Reference: 4
Screw, stop
Diagram Reference: 5
Screw
Diagram Reference: 6
Washer, plate(65j)
Diagram Reference: 7
Collar
Diagram Reference: 8
Throttle sensor assembly
Diagram Reference: 9
Bracket
Diagram Reference: 10
Screw, with washer(6g7)
Diagram Reference: 11
Collar(6k7)
Diagram Reference: 12
Grommet(6k7)
Diagram Reference: 13
Washer
Diagram Reference: 14
Screw, with washer(61b)
Diagram Reference: 15
Lever
Diagram Reference: 16
Spring
Diagram Reference: 17
Rod, accel. lever
Diagram Reference: 18
