30AMH (1992)
Fuel
Diagram: Fuel
Parts List
Reference
Description
Price
4
6Y1242600200
Fuel meter assembly
Loading…
↗
6
985860501600
Screw, pan head
Loading…
↗
7
6Y1243290000
Seal
Loading…
↗
8
6Y1246100000
Cap assembly
Loading…
↗
9
6Y1241670000
Strainer
Loading…
↗
11
6Y1243060500
Fuel pipe comp. 1
Loading…
↗
12
9044511M8100
Hose (l3000)
Loading…
↗
13
6Y1243600200
Primer pump assembly
Loading…
↗
14
9044511M0500
Hose (l1000)
Loading…
↗
15
650243510100
Band 1
Loading…
↗
16
6G1243050500
Fuel pipe joint comp. 2
Loading…
↗
17
932100828700
O-ring (655)
Loading…
↗
18
6Y1243050100
Fuel pipe joint comp. 2
Loading…
↗
20
6G1243040200
Fuel pipe joint comp. 1
Loading…
↗
21
970800602000
Bolt(7u8)
Loading…
↗
22
929900660000
Washer, plain (646)
Loading…
↗
23
9044509M2500
Hose (l1500)
Loading…
↗
24
904670800400
Clip, pipe 6162435600
Loading…
↗
25
655245600100
Filter assembly
Loading…
↗
26
6F5245630000
Element, filter
Loading…
↗
27
9321037M2500
O-ring (655)
Loading…
↗
29
648245660100
Bracket, Filter
Loading…
↗
30
970130601200
Bolt(gh1)
Loading…
↗
31
953800860000
Nut (661)
Loading…
↗
32
689243110000
Hose
Loading…
↗
34
692244100000
Fuel pump assembly
Loading…
↗
35
648244110000
Diaphragm
Loading…
↗
36
648244240000
Seat,spring
Loading…
↗
37
648244230000
Spring,diaphragm
Loading…
↗
38
648244340100
Gasket, body
Loading…
↗
39
6A0244210100
Valve, check
Loading…
↗
40
6A0143250000
Screw, pan head
Loading…
↗
41
953800360000
Nut (6g8)
Loading…
↗
42
648244350200
Gasket, body 2
Loading…
↗
43
663244110000
Diaphragm
Loading…
↗
44
648244130100
Cover, pump
Loading…
↗
45
985800553000
Ybs86-530 screw,panhead
Loading…
↗
46
929900510000
Ybs67-5 washer, spring
Loading…
↗
47
65024431A000
Gasket,fuel pump
Loading…
↗
48
973950604000
Bolt (682)
Loading…
↗
50
648243120100
Pipe, fuel 1
Loading…
↗
52
656W28100100
Tool kit
Loading…
↗
53
6E0281930094
Plug, water check
Loading…
↗
